Features of PP Fiber Waste Recycling Line
- Raw Material: PP Fiber Waste
- Final Product: Recycled PP Pellets
- Recycling Capacity: 500-600 kg/h
- Total Power: approx. 430 kW
- Energy Consumption: approx. 0.35 kWh/kg
PP Fiber Waste Recycling Process
PP Fiber Waste → Belt Conveyor → Metal Detector → Double Single Shaft Shredder Machine → Belt Conveyor →Buffer Storage Hopper → Belt Conveyor → Metal Detector → Screw Densifier → Double Stage Pelletizing Line (Extruder → Double-Station Screen Changer → Extruder → Double Column Hydraulic Screen Changer) → Water-Cooling Strand Pelletizing System → Vibrating Screen → Storage Hopper → Recycled PP Pellets
Equipment List of PP Fiber Waste Recycling System
- PNDS-1000D Double Single Shaft Shredder
- Two-Stage Pelletizing Line
- Water-Cooling Strand Pelletizing System
- Belt Conveyor 3
- Metal Detector 2
- Buffer Storage Hopper
- Screw Densifier
- Vibrating Screen
- Storage Hopper
Description of the PP Fiber Waste Recycling System
1. Belt Conveyor & Metal Detection
Flighted belt conveyor provides stable feeding of lightweight PP fiber waste into the shredder. Integrated metal detectors remove metal contaminants to protect cutting blades and improve equipment reliability.
2. Double Single Shaft Shredder Machine
Model: PNDS-1000D
- Dual 55+55 kW motors with No.7 gearbox for high torque shredding.
- Two rotor shafts designed for efficient PP fiber waste processing.
- DC53/tungsten carbide square knives with four usable cutting edges.
- Fixed knives feature four-side replaceable design for longer service life.
- Adjustable output size: 30–80 mm
3. Buffer Storage Hopper
Variable-frequency buffer hopper with agitator prevents material bridging and ensures stable feeding. Conveyor metal detection removes remaining metal impurities before extrusion.
4. Screw Densifier Feeding Equipment
Power: 5.5 kW. Replaces traditional 160 kW agglomeration feeding systems.
Provides compact and continuous feeding while significantly reducing energy consumption and improving extrusion stability.
5. Two-Stage Pelletizing Line
Extruder No.1
180 mm screw diameter. High feeding capacity and plasticizing efficiency.
Single-plate double-station screen changer for impurity filtration.
Extruder No.2
160 mm screw diameter. Main motor: 55 kW. Heating power: 24 kW.
Double-column hydraulic screen changer enables continuous operation without stopping production.
6. Water-Cooling Strand Pelletizing System
- Equipped with 7.5 kW automatic water traction system.
- Provides stable strand cooling and cutting.
- Reduces manual operation and improves pelletizing consistency.
7. Vibrating Screen
Filter out plastic pellets that are too large
8. Storage Hopper
Storage of PP pellets
