PVC Plastic Pulverizer Mill Knives Blades

Our factory have imported two sets of the Japan CNC machine which are specially used to produce the Plastic Pulverizer Blade, Pulverizing disc, Grind Mill, Mill Disc, Grinding Disc, Granulator Disc, pulverizing disc, they can make sure the high quality of the blades, disc or mill quality! At the same time

Features

UHMWPE Pulverizer grinder,UHMWPE Pulverizer mill ,UHMWPE Grinder Machine, Pulverizer grinder,pulverizer plastic, Plastic Grinder Machine

Model PNMF-300 PNMF-400 PNMF-500 PNMF-600 PNMF-800
Disc
Diameter(mm)
300mm 400mm 500mm 600mm 800mm
Dimension L,W,H(mm) 3700,1500,3700 3800,1600,3800 3900,1700,3900 4000,1800,4000 4300,1900,4300
Main Motor(kw) 11-15 22-30 30-37 45-55 75-90
Air Blower(kw) 3 4 5.5 5.5kw 7.5
Vibrating
Motor (kw)
0.55 0.55 0.75 1.1 1.1
Air Lock
Motor (kw)
0.75 0.75 0.75 0.75 0.75
Capacity
(kg/h)
30-50 50-120 120-200 200-350 400-600

Our factory have imported two sets of the Japan CNC machine which are specially used to produce the Plastic Pulverizer Blade, Pulverizing disc, Grind Mill, Mill Disc, Grinding Disc, Granulator Disc, pulverizing disc, they can make sure the high quality of the blades, disc or mill quality! At the same time, we use the D2 material, after treatment, the blades have the feature of high hardness, up to 60-63HRC, and anti-wearing! One set of the blades can produce 300-500tons PE or PP plastic granules! If for the PPMC, HIPS, PET, PVC etc some special hard or rigid material, which can cause the grinding disc, mill or blades wearing quickly, we can coat one layer of the WC, TiAlN etc specially alloy metal powder, it can make the Plastic Pulverizer Blade¡¯s service time three or four times comparing with the common blades, mill or disc!

Detail:

PVC Plastic Pulverizer Mill Knives Blades
