PP PE PS PET PVC Plastic Compounding Pelletizing Line PP PE PS PET PVC Plastic Compounding Pelletizing Line

PP PE PS PET PVC Plastic Compounding Pelletizing Line Process flow:
Screw feeder---high speed mixer---- screw loader----Double screw metering feeder— Parallel twin screw extruder—single screw extruder---hydraulic screen change—hot face cutting device—first step cyclone separator—second step cyclone separator—vibration sieve—silo

Quantity:
Share this:
  • Product Description
  • Parameters
  • Video

Description:
The compounding pelletizing line plastic film densifier machine is composed of two sets of extruder to form the main body, with reasonable design, applied to the recovery of high water content film and all kinds of foaming material, which has a remarkable effect and can ensure the sol mixing effect and particle density. Vacuum exhaust system increases exhaust volume, making the volatile off more completely. The optimization of the forced feeding system greatly increases production capacity.


Process flow:
Screw feeder---high speed mixer---- screw loader----Double screw metering feeder— Parallel twin screw extruder—single screw extruder---hydraulic screen change—hot face cutting device—first step cyclone separator—second step cyclone separator—vibration sieve—silo

PP PE PS PET PVC Plastic Compounding Pelletizing Line


Features:
Applicable to the production of the pp /pe /pet /ps regeneration of a variety of plastic and color mixing granulation.
Gearbox design with high torque, low noise and smooth running performance.
Screw, barrel after special surface treatment, wear, mixing effect, high yield characteristics.
Vacuum exhaust or design natural exhaust port, the production process will exclude water, waste gas, resorted more stable, denser, to ensure the good quality of the product.
 According to different uses and production of pellets, select appropriate models with flat shaped twin screw extruder.
Application :
Applicable plastics material:PP,BOPP,CPP,PE,HDPE,LDPE,LLDPE,PET,PA,EPE etc.
Material shapes: film, printed LDPE film, film(rolls, loose, bundled), agriculture film waste, this type machine also be suitable for the bag, woven bag, foamed plastic(EPE), raffia and hard flakes.

Plastic Compounding Pelletizing Line,Compounding & Pelletizing Line,Compounding Granulation Machine ,PVC Compounding Granulating,PVC Compounding Pelletizing

ModelScrew Diameter(mm)L/DRotate Speed(rpm)Main Motor(kw)Capacity(kg/h)
SJPT2021.732-4060042-10
SJPT353528-4840018.55-30
SJPT5050.528-40400/60011/1540-80
SJPT6562.428-48500/60055/75100-300
SJPT7271.228-48400/50090/110300-600
SJPT9291.728-40400/500220/250600-100



×
