PP PE PET Plastic Bottle Perforating Machine PP PE PET Plastic Bottle Perforating Machine

• High output and low energy consumption • Large working capacity greatly improves throughput and operational efficiency • Reduces bale size and the likelihood of straps breaking or warping • Can perforate empty or full plastic bottles with or without caps on • Can perforate plastic bottles up to 3.78 liter

Quantity:
Share this:
  • Product Description
  • Parameter

Description:
The Bottle Perforating Machine is a machine designed to punch holes in plastic bottles using internal spikes before they are compacted by a baler in order to release any potential air from a bottle. After the plastic bottles are perforated, they can be compacted effectively into more homogeneous, more compact and heavier bales. The Bottle Perforating Machine removes the risk of bales exploding from a pressure increase from the leftover air in some compacted bottles, as well as the risk of straps or ties snapping due to the same pressure. The Bottle Perforating machine is absolutely essential to the plastic bottle compacting process. This bottle perforating machine has upgraded by widening the distance between two shafts of the machine and lengthening the tapered needles to 8 cm.  This feature has enabled the perforator cannot only perforate small plastic bottles such as 500ml or 1litre, but can also perforate bigger HDPE containers sufficiently.

Application:
The bottle perforator machine is mainly designed to perforate plastic bottles(PET/PP/PE, ETC) before these bottles go into the baler.

Functions:
After perforation, this plastic bottle can be compacted effectively into bales that are more homogeneous, dense and heavier. The perforated bottles protect bales from the risk of wires snapping due to rising pressure caused by the air bubbles left behind in the compacted material. With the bottle perforator, the air can now escape through the perforation holes. During the compacting of non-perforated bottles, many still containing their caps, isolated air bubbles remain in the bale. When the temperature rises due to exposure to the sun, the temperature increases and then the wire ties around the bale may snap.

Features:
• High output and low energy consumption
• Large working capacity greatly improves throughput and operational efficiency
• Reduces bale size and the likelihood of straps breaking or warping
• Can perforate empty or full plastic bottles with or without caps on
• Can perforate plastic bottles up to 3.78 liter

Perforating Roller Length1500mm
Perforating Roller Diameter340mm
Rotate Speed1450r/min
MotorSiemens/Beide
Electrical ElementSchneider
Power7.5kw
Capacity2000kg/h
Weight approx.2330kgs
Machine Dimension2000 x 1000 x 2200mm
Suitable MaterialPE/PP/PET/PVC
Feeding Mouth1800 x 1200mm
Lead Time40 days
MOQ1 set
Package2580kgs/9.92cbm


×
